Get access to NanoIC's PDKs

Design tomorrow's semiconductor technologies through the NanoIC pilot line.

The NanoIC pilot line is being developed to accelerate innovation beyond the 2nm technology node.

To enable researchers and designers to engage with these emerging technologies at an early stage, NanoIC provides advanced process design kits (PDKs): technology-specific design toolkits containing the models, design rules, and libraries needed to accurately simulate, design, and verify advanced chips.

Why use NanoIC’s PDK?

  • Stay ahead of the technology roadmap
    Assess the feasibility and potential impact of next-generation logic, memory and interconnect technologies before they become commercially available.
  • Design with advanced technologies today
    Work in realistic beyond-2nm design environments to explore new concepts, improve your skills or validate ideas.
  • Reduce development risks
    Benchmark architectures, system concepts and design decisions.
  • Accelerate development
    Shorten the path from concept to validation by exploring new technologies, architectures and design approaches at an early stage.
  • Prepare for future prototyping
    Build knowledge, IP and design expertise that can later be translated into hardware demonstration and pilot-line activities.


Which PDKs does NanoIC have to offer?

NanoIC offers a growing portfolio of advanced process design kits (PDKs) for logic, memory and interconnect technologies beyond the 2nm node.

Click on an item below to see the technical specifications of each PDK.

Currently available

Logic

Logic N2 PDK V1.0

PDK description

The N2 Pathfinding PDK provides a complete digital design enablement environment for advanced nanosheet-based technologies ahead of silicon availability. It includes T-CAD calibrated device and interconnect models, design rules, standard-cell libraries, SRAM macros with timing and behavioural models, and the infrastructure required for commercial EDA flows. The PDK enables RTL-to-GDSII implementation, PPA benchmarking, and full SoC architecture exploration using both frontside and backside power delivery schemes.

Technical specifications

CategorySpecification / key parametersIncluded content and enablement
Technology platformN2 nanosheet technology with TSVM-based backside connectivityDigital Pathfinding PDK for advanced logic design, design-technology co-optimization (DTCO), and architecture exploration.
Device architectureGate-all-around nanosheets
CPP: 48 nm
Gate length: 15 nm
Compact device models and parasitic representations based on the N2 pathfinding process assumptions.
Power delivery architectureFrontside and backside power delivery options
Backside connection: TSVM to the device side
Supports evaluation of frontside and backside power delivery schemes within digital implementation studies.
Routing stack17 routing metal layers
Frontside: M0-M12 (13 layers)
Backside: B0-B3 (4 layers)
Technology definitions, routing-layer information, interconnect models, and extraction collateral.
Local interconnectM0 pitch: 22 nmRC modeling and extraction support for timing and power evaluation.
Standard-cell library102 standard cells
6-track architecture
Cell height: 132 nm
Electrically characterized logic library with timing, power, physical abstract, layout, and implementation views.
Device flavorsULVT, LVT, SVT, and HVTMultiple threshold-voltage options supporting performance, power, and memory optimization.
PVT coverageVDD characterization: 0.5 V, 0.7 V, and 0.9 V
Process corners: TT, SS, and FF
Temperature range: 20 °C to 125 °C
Characterization collateral for timing, power, and process-voltage-temperature evaluation.
Embedded memory support29 SRAM macro instances
TSVM and M0 variants
SRAM macros with Liberty and LEF views for realistic memory-subsystem integration.
Technology filesICT files, technology definitions, routing data, and extraction collateralProvides the technology setup required by supported implementation and extraction flows.
DocumentationDesign Rule Manual, User Guide, compact-model release notes, and process assumptionsReference documentation for PDK installation, technology understanding, and design enablement.

The N2 Pathfinding PDK provides a comprehensive digital design enablement platform for nanosheet-based logic technologies featuring TSVM-enabled backside connectivity. The release includes calibrated device and interconnect models, a characterized 102-cell standard-cell library, 29 SRAM macros, physical verification decks, technology files, documentation, and complete Cadence and Synopsys flow support. Together, these capabilities enable RTL-to-GDSII implementation, PPA analysis, DTCO studies, memory subsystem integration, and advanced SoC architecture exploration.

Supported design tools

  • Cadence Innovus with sub-3 nm technology licenses
  • Synopsys Fusion Compiler
Logic A14 PDK v0.0

PDK description

The A14 pathfinding PDK is based on projected performance of the technology developed in the imec NanoIC pilot line and supports early Design-Technology Co-Optimization (DTCO) to give guidance on process assumptions and design rules. It enables early design assessments in advanced technologies, bridging the gap between technology and design communities from academia and industry.

Compared to N2, the A14 technology differs mainly by the contacting scheme to connect the backside metals to the devices: while N2 used TSVM, A14 assumes direct Backside contact (BCT) to the source/drain EPI from the BSPDN as technology booster. This leads to a more compact structure with smaller silicon footprint. This evolution in contacting scheme reflects the roadmap foreseen in backside enablement, with increasing processing complexity but also performance.

Technical specifications

CategorySpecification / key parametersIncluded content and enablement
Technology platformA14 nanosheet technology with BCT-based backside connectivityDigital Pathfinding PDK for advanced logic design, DTCO studies, architecture exploration, and backside power-delivery evaluation.
Device architectureGate-all-around nanosheets
CPP: 45 nm
Gate length: 15 nm
Compact device models and parasitic representations based on A14 pathfinding technology assumptions.
Power delivery architectureBackside power delivery
Backside connection: BCT (Backside Direct Contact to Device)
Enables evaluation of advanced backside power delivery and routing schemes for next-generation standard-cell and SRAM architectures.
Routing stack18 routing metal layers
Frontside: 13 layers
Backside: 5 layers
Technology definitions, routing-layer information, interconnect models, and extraction collateral supporting implementation and signoff studies.
Standard-cell library162 standard cells
Cell height: 115 nm
Electrically characterized logic library including timing, power, physical abstract, layout, and implementation views for RTL-to-GDSII flows.
Device flavorsULVT, LVT, SVT, and HVTMultiple threshold-voltage options supporting performance optimization, leakage management, and design-space exploration.
PPA improvements vs N2Area gain: ~18% w.r.t. N2
Power reduction: ~7% at iso-frequency
Enables comparative DTCO studies and technology benchmarking versus the N2 platform.
PVT coverageVDD characterization: 0.5 V, 0.7 V, and 0.9 VCharacterization collateral for timing and power evaluation across supported operating voltages.
Technology filesICT files, technology definitions, routing data, extraction collateral, and implementation setup filesProvides the technology infrastructure required by supported synthesis, implementation, extraction, and signoff flows.
DocumentationDesign Rule Manual, User Guide, compact-model release notes, technology assumptions, and collateral documentationReference documentation for PDK installation, technology understanding, flow setup, and design enablement.

Supported design tools

  • Cadence Innovus with sub-3 nm technology licenses
  • Synopsys Fusion Compiler

Memory


Memory

Memory eDRAM PDK V0.0

PDK description

The IGZO-based eDRAM PDK aims at providing the user with tools and models enabling universities, startups, industry players in the EU ecosystem to explore a multitude of application-specific, novel memory concepts for eDRAM architectures at a simulation level.

Technical specifications

The IGZO-based eDRAM PDK is based on imec's roadmap and experimental results associated with its IGZO-based, BEOL-embedded eDRAM Technology. This version enables design at simulation level of application-specific novel memory concepts, based on models calibrated on the best available IGZO device experimental data. It allows the combination of eDRAM device models and BEOL-embedded bitcells with third-party CMOS frontend technologies (the latter needs to be provided by the user through a suitable PDK installation).

This PDK contains models of selected IGZO eDRAM bitcell architectures, selected based on early Design-Technology Co-Optimization (DTCO) efforts, complemented with the extracted parasitics associated with specific physical implementations designed under the assumption of N40 or N7 technology rules.

IMEC IGZO-based eDRAM Technology specification sheet
ItemsParameters
TFT semiconductor materialIGZO
Gate length40 nm
Minimum metal layer levels4
Bitcell configurations2T0C, 3T0C
TFT variants in bitcellFront-gate or back-gate
Design rules compatibilityN40 or N7 nodes
Bitcell flavours5*
Vdd - Nominal1 V
Temperature operational range25 – 100 °C

* Only selected combinations of bitcell configuration, TFT variant, and design-rule compatibility are available.

PDK contents

The IMEC IGZO-based eDRAM Technology PDK v0.0 contains:

  • An OA library with symbols for simulation of IGZO FET devices, IGZO-based eDRAM bitcells compatible with a N40 frontend technology, IGZO-based eDRAM bitcell compatible with a N7 frontend technology.
  • A compact model for the IGZO FET device compatible with IMEC's eDRAM Technology
  • Netlists including RC parasitics for eDRAM Technology bitcells in specific physical implementations within the BEOL
  • PDK/library setup files
  • Documentation: Technology reference, Models guide, User guide.

Supported design tools

The IGZO-based eDRAM PDK v0.0 has been tested and is compatible with:

  • Cadence Spectre 21.10.208
  • Cadence IC6.1.8 ISR26

In case the user sets up this PDK to work in Add-on mode (Section 3.2), it is responsibility of the user to verify the compatibility of the EDA software tools and versions with the chosen base third-party PDK.

Interconnect


Interconnect

Interconnect D2W hybrid bonding PDK V0.0

PDK description

The Die-to-Wafer hybrid bonding PDK from imec brings a new level of high-density chip-to-chip integration, enabling ultra-dense die-to-die 3D connections.

D2W hybrid bonding enables high-density integration by providing extremely compact, direct connections between dies in the third dimension. Instead of relying on traditional copper bumps, hybrid bonding forms direct oxide-to-oxide links between the CMOS die and the package interface. This eliminates the parasitic effects associated with copper bumping and enables low-loss, energy-efficient communication pathways.

The PDK provides designers with access to highly dense die-to-die 3D connections, early process assumptions, design rules, and wafer-level packaging insights. This supports the development of next-generation advanced packaging designs in Europe and helps train the design community.

Technical specifications

The first release of PDK is version v0.0. It is an alpha version primarily used for evaluation purposes.

ItemsParameters
Scaled pitch die to wafer (hybrid bonding)Available, 2 µm pad pitch
Width, space of metal line (M1)0.5 µm, 0.5 µm
Width, space of via (VIA)min 0.4 µm / max 0.6 µm, 0.4 µm
Width, space of metal line (M2)0.3 µm, 0.5 µm

The PDK contains the necessary infrastructure and design kits for advanced interconnect design, including:

  • Instruction of PDK installation and setup environments
  • Design manual including description process, CAD layer definitions, and geometric rules of layers
  • CDS environment to use Cadence Virtuoso for custom layout design
  • DRC rule file to run Calibre for physical verification
  • Layer map file for layout editors

Supported design tools

  • Operating system: Red Hat Enterprise Linux 8.10
  • CDS environment: Version of Virtuoso provided by Cadence: v25.10.030
  • DRC: Version of Calibre provided by Siemens: v2025.4_36.20
  • Reference flow:
    • Version of Integrity 3D IC provided by Cadence: v25.12.000
    • Version of Innovus provided by Cadence: v25.12.000
Interconnect Fine-pitch RDL PDK v0.0

PDK description

The fine-pitch redistribution layer PDK brings a new level of high-density chip-to-chip integration, enabling RDL with micro-bump on advanced polymer-based substrates.

The fine-pitch RDL PDK provides designers with early access to high-density polymer-based die-to-die interconnects, including process assumptions, design rules, and wafer-level packaging insights. It supports the development of advanced packaging designs in Europe and helps train the design community.

Technical specifications

The first release of PDK is version v0.0. It is an alpha version primarily used for evaluation purposes.

ItemsParameters
Micro bump pitch20 µm
Width, space of RDL1.3 µm, 1.3 µm
Width, space of via (VIA)1.3 µm, 1.3 µm

The PDK contains the necessary infrastructure and design kits for advanced interconnect design, including:

  • Instruction of PDK installation and setup environments
  • Design manual including description process, CAD layer definitions, and geometric rules of layers
  • CDS environment to use Cadence Virtuoso for custom layout design
  • DRC rule file to run Calibre for physical verification
  • Layer map file for layout editors

Supported design tools

  • Operating system: Red Hat Enterprise Linux 8.10
  • CDS environment: Version of Virtuoso provided by Cadence: v25.10.030
  • DRC: Version of Calibre provided by Siemens: v2025.4_36.20
  • Reference flow:
    • Version of Integrity 3D IC provided by Cadence: v25.12.000
    • Version of Innovus provided by Cadence: v25.12.000

Coming up


Logic A7 PDK v0.0 - Launch early 2027
Memory SOT S-MRAM PDK v0.0 - Launch end 2026
Interconnect Silicon Interposer PDK v0.0 - Launch early 2027
